Circular Gallery

npx shadcn@latest add https://satisui.xyz/r/circular-gallery.json

npm install gsap @gsap/react
# or
yarn add gsap @gsap/react
# or
pnpm add gsap @gsap/react

'use client';

import React, {
  useRef,
  forwardRef,
  useImperativeHandle,
  CSSProperties,
} from 'react';
import Image from 'next/image';
import { gsap } from 'gsap';
import { ScrollTrigger } from 'gsap/ScrollTrigger';
import { useGSAP } from '@gsap/react';
import { clsx, type ClassValue } from 'clsx';
import { twMerge } from 'tailwind-merge';

function cn(...inputs: ClassValue[]) {
  return twMerge(clsx(inputs));
}

if (typeof window !== 'undefined') {
  gsap.registerPlugin(ScrollTrigger);
}

export interface GalleryItem {
  src: string;
  alt: string;
  key?: string;
  onClick?: () => void;
}

/**
 * Props for the CircularGallery component.
 */
interface CircularGalleryProps extends React.HTMLAttributes<HTMLDivElement> {
  items: GalleryItem[];
  /** Base radius of the 3D cylinder in pixels for desktop screens. Defaults to 700. */
  radius?: number;
  /** Radius for mobile screens (<768px). Defaults to half of `radius`. */
  mobileRadius?: number;
  /** Total scroll height in pixels. Determines the speed of rotation relative to scroll depth. */
  scrollDistance?: number;
  /** Total rotation in degrees that occurs over the `scrollDistance`. Defaults to -360. */
  rotationTotal?: number;
  /** Width of each gallery item in pixels. */
  itemWidth?: number;
  /** Height of each gallery item in pixels. */
  itemHeight?: number;
  /** CSS perspective value for the 3D container. */
  perspective?: number;
  ariaLabel?: string;
}

interface CustomCSSProperties extends CSSProperties {
  '--radius-desktop'?: string;
  '--radius-mobile'?: string;
}

/**
 * A 3D circular gallery component that rotates elements around a central Y-axis
 * based on the user's vertical scroll position.
 *
 * Utilizes GSAP ScrollTrigger for animation and standard Shadcn UI/Tailwind
 * semantic classes for theming.
 */
const CircularGallery = forwardRef<HTMLDivElement, CircularGalleryProps>(
  (
    {
      items,
      radius = 700,
      mobileRadius,
      scrollDistance = 2000,
      rotationTotal = -360,
      itemWidth = 256,
      itemHeight = 384,
      perspective = 1000,
      ariaLabel = '3D Circular Gallery',
      className,
      ...rest
    },
    ref
  ) => {
    const containerRef = useRef<HTMLDivElement>(null);
    const carouselRef = useRef<HTMLUListElement>(null);

    useImperativeHandle(ref, () => containerRef.current!);

    const actualMobileRadius = mobileRadius ?? radius * 0.5;

    useGSAP(
      () => {
        if (!carouselRef.current || !containerRef.current) return;

        const mm = gsap.matchMedia();

        const setupScroll = (startPosition: string) => {
          const tl = gsap.timeline({
            scrollTrigger: {
              trigger: containerRef.current,
              pin: true,
              start: startPosition,
              end: `+=${scrollDistance}`,
              scrub: 1,
              invalidateOnRefresh: true,
              fastScrollEnd: true,
            },
          });

          tl.to(carouselRef.current, {
            rotationY: rotationTotal,
            ease: 'none',
          });
        };

        mm.add('(min-width: 768px)', () => setupScroll('top top'));
        mm.add('(max-width: 767px)', () => setupScroll('center center'));
        mm.add('(prefers-reduced-motion: reduce)', () => {
          if (carouselRef.current)
            gsap.set(carouselRef.current, { rotationY: 0 });
        });
      },
      { scope: containerRef, dependencies: [scrollDistance, rotationTotal] }
    );

    if (!items || items.length === 0) return null;

    const angleIncrement = 360 / items.length;

    return (
      <div
        ref={containerRef}
        className={cn(
          'relative flex min-h-screen w-full flex-col items-center justify-center overflow-hidden bg-background py-12 z-10',
          className
        )}
        {...rest}
      >
        <div
          className='relative flex h-full w-full items-center justify-center'
          style={{ perspective: `${perspective}px` }}
        >
          <ul
            ref={carouselRef}
            className={cn(
              'group relative flex h-0 w-0 items-center justify-center will-change-transform',
              '[--radius:var(--radius-mobile)] md:[--radius:var(--radius-desktop)]'
            )}
            style={
              {
                transformStyle: 'preserve-3d',
                '--radius-desktop': `${radius}px`,
                '--radius-mobile': `${actualMobileRadius}px`,
              } as CustomCSSProperties
            }
            role='list'
            aria-label={ariaLabel}
          >
            {items.map((item, index) => {
              const uniqueKey = item.key || `${item.src}-${index}`;
              const angle = angleIncrement * index;
              const isInteractive = !!item.onClick;

              return (
                <li
                  key={uniqueKey}
                  role={isInteractive ? 'button' : 'listitem'}
                  tabIndex={isInteractive ? 0 : -1}
                  onClick={item.onClick}
                  onKeyDown={(e) => {
                    if (isInteractive && (e.key === 'Enter' || e.key === ' ')) {
                      e.preventDefault();
                      item.onClick?.();
                    }
                  }}
                  className={cn(
                    'absolute overflow-hidden rounded-2xl border border-border bg-card shadow-sm',
                    'transition-all duration-700 ease-[cubic-bezier(0.25,0.4,0.25,1)]',
                    isInteractive ? 'cursor-pointer' : 'cursor-default',
                    // Group hover logic
                    'group-hover:opacity-25 group-hover:blur-[3px] group-hover:grayscale',
                    // Active logic
                    'hover:!opacity-100 hover:!blur-none hover:!grayscale-0 hover:border-primary hover:ring-2 hover:ring-primary/20',
                    'focus-visible:outline-none focus-visible:ring-4 focus-visible:ring-ring focus-visible:ring-offset-2'
                  )}
                  style={{
                    width: `${itemWidth}px`,
                    height: `${itemHeight}px`,
                    marginLeft: `-${itemWidth / 2}px`,
                    marginTop: `-${itemHeight / 2}px`,
                    transform: `rotateY(${angle}deg) translateZ(var(--radius)) rotateY(-180deg)`,
                    backfaceVisibility: 'hidden',
                  }}
                >
                  <div className='relative h-full w-full bg-muted'>
                    <Image
                      src={item.src}
                      alt={item.alt}
                      fill
                      sizes='(max-width: 768px) 100vw, 30vw'
                      className='object-cover select-none pointer-events-none'
                      priority={index < 4}
                    />
                    {/* Vignette overlay */}
                    <div
                      className='absolute inset-0 bg-foreground/10 transition-colors duration-700 hover:bg-transparent'
                      aria-hidden='true'
                    />
                  </div>
                </li>
              );
            })}
          </ul>
        </div>
      </div>
    );
  }
);

CircularGallery.displayName = 'CircularGallery';

export default CircularGallery;

import CircularGallery from '@/components/circular-gallery';

const galleryItems = [
  { src: '/images/photo1.jpg', alt: 'Photo 1' },
  { src: '/images/photo2.jpg', alt: 'Photo 2' },
  { src: '/images/photo3.jpg', alt: 'Photo 3' },
  { src: '/images/photo4.jpg', alt: 'Photo 4' },
  { src: '/images/photo5.jpg', alt: 'Photo 5' },
  { src: '/images/photo6.jpg', alt: 'Photo 6' },
];

export default function GalleryDemo() {
  return (
    <div className='h-[400vh]'>
      <div className='flex h-screen items-center justify-center'>
        <h1 className='text-4xl font-bold'>Scroll Down</h1>
      </div>

      <CircularGallery
        items={galleryItems}
        radius={900}
        itemWidth={300}
        itemHeight={450}
      />

      <div className='flex h-screen items-center justify-center'>
        <h1 className='text-4xl font-bold'>End of Gallery</h1>
      </div>
    </div>
  );
}
